Name: KY5 three Wheel motorcycle electic car express car express truck cargo car
Brand: https//www.donmuc.com
SKU: KY5
Price: 847.00 USD
Availability: InStock
Rating: 5 (1 reviews)

Item No.: KY5

Good looking appearance, luxury full stamping type simple shed, The roof is removable, facilitate transport;
Steering Handle control; Left and right combination switch, simple and convenient control,
LED display very clear, USB phone charging port.

Sale: 0

$847.00

/ set

set(Min. Order)

ZJ160:

ZJ160 EU

$0.00

set

(68000 In Stock)

ZJ160 AM

$0.00

set

(65200 In Stock)

ZJ160 BR

$0.00

set

(49850 In Stock)

ZJ160 in

$0.00

set

(63200 In Stock)

ZJ160motor

$665.00

set

(60620 In Stock)

All 5 Options

$0.00

Selected List

No Selected Products

Payment:

Request Quote Contact Us PDF Format

Make Money

Like this product?

Join us to promote this product via an exclusive coupon code !

Description FAQ Review

Description

Unit Price	FOB USD 1721
Loading quantity	24 units in 40‘HQ in CKD
Specifications
Overall Size	353014351860mm	Rear Shock Absorber	8 pcs Leaf spring
Cargo Box Size	22001350340mm	Rear Axle	Chang'an entire floating rear axles /oil break/ 2gear booster/30:12
Engine	200cc/ Single cylinder/ 4 stroke/water cooling	Minimum Turning Circle Diameter	7000mm
Rated Power	10.3kw / 7500rpm	Min. Ground Clearance	180mm
Max. Torque	14.2N.m /5500rpm	Tyre	5.00-12/5.00-12
Cylinder Bore * Stroke	φ63.5mm×62.2mm	Brake Type	Oil break
Ignition Mode	CDI	Brake Mode	Drum/ Drum
Controller	10.5:1	Max. Speed	60km/h
Transmission	5 gears/ Cycle gear	Fuel Tank Capacity	16L
Driving Mode	shaft transmission	Curb Weight	545 kg
Gear Ratio	30:12	Maximum Payload	600kg
Front Shock Absorber	φ 36mm/ Hydraulic outer front fork	Max. Designed Gross Weight	1145kg
Optional		250cc water cooling engine; 20001350340mm cargo box
Features	1. Good looking appearance, luxury full stamping type simple shed, The roof is removable, facilitate transport; 2. Steering Handle control; Left and right combination switch, simple and convenient control, LED display very clear, USB phone charging port. Automotive matrix cold light headlamp, high brightness, low energy consumption, long service life; 3. Engine with a new upgraded 200CC water-cooled, left and right side cover to increase the heat sink, the engine cylinder head close to the air duct, matching the main radiator and auxiliary water tank, effectively reduce the engine oil temperature, prolong the service life of the engine. 4. 370*280mm water-cooled radiator, automatically turned on at 65°C, operating power 45W, 220mm diameter suction fan with shroud, equipped with 5L auxiliary water tank and diameter 31/23mm thickened water pipe, more coolant passing through per unit time , the heat dissipation effect is better, which can effectively improve the cooling effect, better protect the engine, and meet the needs of tropical climates; 5. 100m³ double-layer filter and dust-proof large air filter, with larger air intake, suitable for most usage scenarios, and effectively improving the purity of engine air intake; 6. The frame is a straight-through double-layer frame with enlarged main girder, and the chassis frame has a tubular structure, which improves the torsional capacity by 30%. Strong carrying capacity, rough and solid. Provide better stability for your driving; 7. The layout of the joystick has been carefully designed, and the reverse gear lever and the afterburner lever are arranged on the right side, which is more in line with the operating habits and is convenient and labor-saving; the upper-mounted design of the handbrake is more convenient to operate. Equipped with widened seats and passenger-car-grade armrests to make you more comfortable when riding, and the left and right safety armrests help you get on.
